Engine Timing Tool Kit for BMW M3 S65

Specialized engine timing tool kit designed for BMW M3 models equipped with S65 engines. Suitable for timing adjustment, timing chain replacement, camshaft and VANOS unit removal, and general engine repair operations.

Compatibility

Compatible with the following vehicles:

• BMW M3 E90
• BMW M3 E92
• BMW M3 E93

Engine codes:

• S65B40A
• S65B44A

Functions

• Camshaft locking and alignment
• Crankshaft positioning and locking
• VANOS adjustment and fixation
• Support for timing chain service and replacement
• Enables precise engine timing procedures

Scope of Delivery

• 2 pcs camshaft locking tools (119970, 119971, 119972)
• Crankshaft locking pin – Item No. 100211 (115320)
• VANOS adjustment and fixing tool – Item No. 106511 (115370)
• Guide rail bearing bolt removal tool (115290, 115292)
• Screw set (119660)

Important Notes

• VANOS unit removal requires an M5 x 10 mm Allen screw (not longer)
• Disassembly/assembly is not possible without this screw
• Exhaust VANOS gears are spring-loaded
• Central bolts feature left-hand thread

Optional Additional Tools

• Angle gauge with magnetic arm (009120)
• Angle gauge with clip arm (009120)

OEM numbers are for reference purposes only. This product is not an original tool.

BMW 3 Series (E90) (12.2004 - 02.2012) M3 (420 hp, 309 kW)

BMW 3 Series (E90) (12.2004 - 02.2012) M3 CRT (450 hp, 331 kW)

BMW 3 Series Convertible (E93) (05.2006 - 12.2013) M3 (420 hp, 309 kW)

BMW 3 Series Coupe (E92) (03.2006 - 12.2013) M3 (420 hp, 309 kW)

BMW 3 Series Coupe (E92) (03.2006 - 12.2013) M3 GTS (450 hp, 331 kW)

WIESMANN GT MF4 Coupe (09.2003 - ) 4.0 S (420 hp, 309 kW)

WIESMANN MF4 Roadster (03.2009 - ) 4.0 S (420 hp, 309 kW)
